Wooden beam H20 for wall-formwork and slab-formwork system

Wooden beam H20 for wall-formwork and slab-formwork system

    • Wooden beam H20 for wall-formwork and slab-formwork system
    • Wooden beam H20 for wall-formwork and slab-formwork system
    • Wooden beam H20 for wall-formwork and slab-formwork system
  • Wooden beam H20 for wall-formwork and slab-formwork system

    Product Details:

    Place of Origin: China
    Brand Name: HORIZON
    Certification: SGS
    Model Number: Timber beam H20

    Payment & Shipping Terms:

    Minimum Order Quantity: None
    Price: Negotiatable
    Packaging Details: In bundle
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Contact Now
    Detailed Product Description
    Usage: Construction Material: Finland Spruce
    Water-proof: Yes Condition: New
    Supplier: Manufacturer

    As one of the main components of formwork systems,  H20 Timber Beam provides you a complete formwork solutions by combining use with other HORIZON components.




    Advantages:
    1. Light weight and strong rigidity.
    2. Stable in shape due to the highly compressed panels.
    3. Water resistant and anti-corrosion treatment allows the beam more durable in site use.
    4. Standard size can match well with doka or peri systems., universally used all over the world.

    5. Beam end reinforcement ensures extra-long lifespan.

    Technical Data:

    ITEM

    Working Capacity

    Safe operation bending moment

    5KN.M

    Safe operation shear force

    11KN

    Weight

    4.8 kg/m

    Various lengths up to 5.9 m are available.

    made of Finland spruce, water proof painted yellow.
